Specifications:

Additional information

Weight 130 g
Dimensions 120 × 120 × 40 mm
Manufacturer

Rak Wireless

Region

EMEA

Air Interface

LoRa, Wi-Fi

Wi-Fi

2.4Ghz (802.11b/g/n)

LoRa

EU686 8 Channel, RX Sensitivity: -139 dBm (Min),TX Power: 27 dBm (Max), SX1303 mPCIe card (connects maximum of two)

Power Supply

PoE (IEEE 802.3af) – 37~57 VDC

Ethernet Ports

1 LAN 10/100BaseT RJ45

IP Rating

IP67

Operating Temperature

-30˚ C to +55˚ C

Operating Humidity

0-95% RH non-condensing

RAK7289 WisGate Edge Pro 8 Channel Outdoor LoRaWAN Gateway, EU868, Wi-Fi, Ethernet

£329.00

VAT not included

Out of stock

Linkwave Part Number: 6801-01

WisGate Edge Pro version 2 (RAK7289V2/RAK7289CV2) is the RAK’s newest outdoor LoRaWAN gateway.

It is based on the latest SX1303 LoRa core, providing better sensitivity and improved performance.

This Gateway is available in an 8-channel version to help you utilize the maximum of the used LoRaWAN channels in your region.

The gateway supports multi-backhaul with Ethernet, Wi-Fi, and Cellular connectivity. Optionally there is a dedicated port for different power options and full integration with RAK Battery Plus off-grid power solution. The gateway’s new enclosure design allows the LTE, Wi-Fi, and GPS antennas to be inside the enclosure.

The gateway can be remotely managed with the WisDM platform.

It comes with the newest WisGateOS 2 which provides all the existing features but adds a new design, many options, and tooltips. It comes with extension add-ons – an option to add and manage additional features catering to your needs.

FEATURES:

  • PoE (802.3af) + Surge Protection
  • Dual LoRa Concentrators for up to 8 channels
  • Backhaul: Wi-Fi, LTE and Ethernet
  • WisGateOS 2
  • Built-in Network Server
  • LoRaWAN 1.0.3 (LoRaWAN 1.0.4 for the Built-in server is coming soon)
  • MQTT v3.1 Bridging with TLS encryption(compatible with ChirpStack LNS)

Product Contents:

  • 1pc Gateway

  • 1pc Ethernet Cable Gland

  • 1pc POE Injector

  • 1pc Mounting Brackets

  • 1set Screws
