| Dimensions | 380 × 36 × 145 mm |
|---|---|
| Manufacturer | CTi |
| Antenna Technology | Cellular |
| Mounting Type | Wall Mount |
| Air Interface | 4G LTE, 3G, 2G |
| Frequency Bands | 2G: 824-960MHz, 3G: 1710-2100MHz, 4G: 2600MHZ |
| VSWR | < 2.0:1 |
| Gain dBi | ~2dBi |
| Impedance (Ohm) | 50Ω |
| Polarisation | Vertical |
| Pattern | Omnidirectional |
| Cable Type | LMR195 |
| Connector Type | SMA Plug |
| Cable Length | 5m, 10m, 15m |
| Operational Temperature | -40ºC to 85ºC |
£19.60 ex VAT
The AO100/4G is based around the popular wall-mounted AO100. It has the same convenient mounting and external dimension but now comes with a new internal structure that expands the bandwidth to include the newly implemented bands used by LTE (4G).
An outdoor antenna supporting 4G, 3G and 2G bands with a stainless steel mounting bracket and 5, 10 or 15 metres of low-loss LMR195 cable, terminated with a straight SMA plug.
