£29.00 ex VAT
In stock
®The C10QM has been developed within the Cavli portfolio as part of a series of LTE Cat 1 modules that adhere to 3GPP release 10. With its LGA form factor, it offers pin compatibility with the C10GS LTE Cat 1/Cat 4 and C20QM LTE Cat 4 modules, allowing for flexible migration and interoperability. The C10QM module includes in-built GNSS featuring Qualcomm® IZat™ location technology Gen8C Lite, ensuring accurate and dependable positioning via GPS, GLONASS, BeiDou/Compass, Galileo, and QZSS. Additionally, it offers support for VoLTE, and SMS over IMS/SG/CS, as well as compatibility with various internet protocols and standard industry interfaces that guarantee unbridled accessibility. The module comes in two variants: C10QM-EAJ for the Europe and Asia market, and C10QM-NA for the North America market. Additionally, with the help of the optional integrated eSIM powered by Cavli Hubble platform, the global connectivity on offer reduces time required to market. The C10QM module was designed with consideration for IoT and M2M applications, hence the module is well suited for tasks such as asset tracking, e-mobility, data loggers, fleet management, and environmental monitoring.
The C10QM module includes an application processor running a Yocto based linux distribution and is capable of supporting multiple peripheral devices. For volume applications, customer applications can be hosted. The SDK includes an API library for common functions and communication protocols, reducing appliciation development time.
The C10QM is available as an LGA package or as a PCIE minicard package. Please contact us for details.
Basic Module Information
Basic Specification
| Processor: | ARM© Cortex™-A7 @Speed up to 1.3GHz |
| RAM: | 256 MB / 512 MB |
| Flash: | 256 MB / 512 MB |
| OS: | Yocto Linux |
Radio Technology
| RAT Used: | LTE Cat 1 with 2G |
| 3GPP Release | 10 |
LTE Bands
| NA: | B2/ B4/ B5/ B7/ B12/ B13/ B17/ B25/ B26/ B66 |
| EAJ: | B1/ B3/ B5/ B7/ B8/ B18/ B19/ B20/ B26/ B28/ B38/ B40/ B41 |
| GSM Bands: | 900 / 1800 MHz |
Internet Protocols
| TCP(S), HTTP(S), MQTT(S), FTP(S), UDP, PPP4 |
Interfaces
| UART | x3 |
| USB 2.0 | x1 |
| SDIO 3.0 | x1 |
| SDC | x1 |
| USIM | x1 |
| JTAG | x1 |
| Network Status indicator | x1 |
| Module Status indicator | x1 |
| SGMII | x1 |
| PCM2 | x1 |
| I2C2 | x1 |
| SPI2 | x1 |
| GPIO2 | x9 |
| Main ANT | x1 |
| GNSS ANT | x1 |
| LCD(DBI 8-bit)2 | x1 |
| ADC | x2 |
Packaging
| Form Factor: | LGA |
| Dimensions: | 37 x 21.8 x 2.8(mm scale) |
| Pin Count: | 233 Pins |
| Other FF: | mPCIe |
Network Speed (Peak Values)
| Cat 1: | DL 10Mbps & UL 5Mbps |
| GSM: | DL 236.8Kbps & UL 236.8Kbps |
Constellation Coverage
| GPS/GLO/GAL/BDS with QZSS |
| Qualcomm Location Suite Gen 8 C lite |
Temperature Range
| Operating Temperature: | -30 oC to 85 oC |
Power Characteristics
| Voltage Range: | 3.6V to 4.5V |
| Typical Voltage: | 3.8V |
| NA | EAJ | |
| TxD Peak Current: | TBD | TBD |
| TxD Idle Current: | TBD | TBD |
| GNSS (Fix) Current: | 90mA | 90mA |
Applicable Region(s)
| EAJ, NA |
Product Variants
| Variant Name | Region | Integrated eSIM | RAM | Flash |
| C10QM-NA-22GNN* | North America | x | 256MB | 256MB |
| C10QM-NA-22GNN* | ✓ | 256MB | 256MB | |
| C10QM-NA-24GNN* | x | 256MB | 512MB | |
| C10QM-NA-24GNN* | ✓ | 256MB | 512MB | |
| C10QM-EAJ-22GNNStock | Europe, Asia and Japan | x | 256MB | 256MB |
| C10QM-EAJ-22GNH* | ✓ | 256MB | 256MB | |
| C10QM-EAJ-24GNN* | x | 256MB | 512MB | |
| C10QM-EAJ-24GNH* | ✓ | 256MB | 512MB |
| Stock Item is stocked | * Contact Linkwave | 1 Optional | 2 Needs SDK | 3 In Progress | 4 Planned |
Features
LTE Cat 1 |
SMS over IMS/SG/CS |
VoLTE Support |
DFOTA Available |
LCD Interface |
Deep Sleep Mode |
Integrated eSIM |
Powered by Cavli Hubble |
Yocto Linux |
Open SDK Support |
USB 2.0 Interface |
2G Fallback |
Applicable industries
Health Care & E-Health |
Retail |
Energy & Utilities |
Manufacturing |
Smart City |
Safety & Security |
Automotive & Logistics |
